Westinghouse 669855 Horizontal Drain Pan Cased Indoor Coil

Product Description

The WESTINGHOUSE 669855 is a horizontal drain pan designed as a direct replacement component for cased indoor evaporator coil assemblies. The drain pan collects condensate produced during normal cooling operation and channels it away from the coil cabinet, protecting surrounding equipment and structural components from moisture damage. This part is installed in horizontal coil configurations where the unit is oriented on its side. HVAC technicians performing coil service, replacement, or maintenance on compatible WESTINGHOUSE cased indoor coil units will find this pan is a purpose-built OEM-style replacement.

This drain pan is intended for use with horizontal-mount cased indoor coil units in residential split-system air conditioning and heat pump applications. It is specifically referenced for use with the C6BH-T and C6BH-X series cased indoor coils, including models C6BH-T24C-A, C6BH-T24C-B, C6BH-X24C-A, and C6BH-X24C-B. This component is typically installed during coil replacement or when the existing pan shows signs of cracking, warping, or biological fouling that compromises condensate drainage.

Key Features

• Designed for horizontal coil orientation to ensure proper condensate capture and drainage
• Direct-fit replacement for specified C6BH-T and C6BH-X series cased indoor coils
• OEM-referenced part number 669855 for straightforward identification and ordering
• Compatible with residential split-system cooling applications requiring horizontal coil mounting

Compatibility

Designed for use with WESTINGHOUSE cased indoor coil models C6BH-T24C-A, C6BH-T24C-B, C6BH-X24C-A, and C6BH-X24C-B in the C6BH-T and C6BH-X series.

Installation Notes

Installation should be performed by a licensed HVAC technician. Disconnect power to the air handler or furnace at the breaker before removing access panels or handling internal components. Ensure the condensate drain line is clear and properly sloped before securing the replacement pan. Verify the pan seats flush within the coil cabinet with no gaps that could allow condensate bypass.

Technical Specifications

• Part Type: Drain Pan
• Orientation: Horizontal
• Used On Item: Cased Indoor Coil
• Compatible Model Series: C6BH-T, C6BH-X

Standard Information

• Brand: WESTINGHOUSE
• Manufacturer Part Number: 669855
