Western Enterprises M1-346-PG Regulator With CGA346

Product Description

The Western Enterprises M1-346-PG is a single-stage adjustable delivery pressure regulator designed for use with medical air. It features a chrome-plated brass body and a high-pressure chamber made entirely of brass. This regulator can handle inlet pressures up to 3000 psi and delivers an adjustable pressure range from 0 to 100 psi.

• Chrome-plated brass body
• Adjustable pressure range from 0 to 100 psi
• Handles inlet pressures up to 3000 psi

Product Highlights

This regulator includes an internal reseating relief valve for over-pressure protection, a sintered filter to enhance safety and extend the regulator's lifespan, and gas-specific DISS outlets. Ideal for use in medical environments, it offers reliable and safe performance for various applications.

Product Information

Standard Information

• Manufacturer: Western Enterprises
• Brand: Western Enterprises
• MPN: M1-346-PG

Technical Specifications

• Diaphragm Material: Neoprene
• Flow Range: 0 to 100 psi
• Gas Type: Medical Air
• Gauge Size: 2 inches
• Inlet Connection: CGA 346 Nut and Nipple
• Inlet Pressure Max: 3000 psi
• Type: Adjustable Single-Stage
