Werner A320014 Swivel Anchor Steel Swivel D-ring

Product Description

The WERNER A320014 is a steel swivel anchor designed for temporary fall protection applications on job sites. It features a swivel D-ring connection with a 2.25-inch opening, allowing lanyard connectors to orient freely and reduce torque loading on the anchor point. Finished in gold for easy visual identification, this anchor meets ANSI Z359.18, OSHA 1910, and OSHA 1926 standards. It is installed by qualified fall protection workers and safety-trained trades personnel on construction and maintenance projects where temporary tie-off points are required.

This swivel anchor is suited for temporary fall arrest and restraint systems on residential and commercial job sites. Typical applications include roofing, steel erection, and elevated maintenance work where a compliant, relocatable anchor point is needed. The swivel D-ring design keeps the connection gate properly loaded regardless of worker movement direction, which is especially useful in leading-edge and overhead work scenarios.

Key Features

• Steel construction for durability in demanding job-site conditions
• Swivel D-ring with 2.25-inch connection opening accommodates standard snap hooks and carabiners
• Swivel action reduces torque on the anchor and keeps the connector gate properly loaded
• Meets ANSI Z359.18, OSHA 1910, and OSHA 1926 standards for fall protection anchors
• Rated for temporary use, supporting quick setup and relocation across work areas
• Gold finish provides fast visual identification on the structure

Compatibility

Designed as a temporary swivel anchor compatible with standard fall arrest lanyards, self-retracting lifelines, and connecting hardware using snap hooks or carabiners that fit a 2.25-inch D-ring opening, as typically used in ANSI-compliant personal fall arrest systems.

Installation Notes

Installation must be performed by a competent person as defined under OSHA 1926 Subpart M and in accordance with ANSI Z359.18 requirements. Always verify the anchor point substrate can support the required load before connecting fall protection equipment. Inspect the swivel action and D-ring for damage before each use. Power down or de-energize adjacent equipment as required by site conditions prior to working at height.
