Weldbend 340-060-000 Raised Face Flange 6 in 300 lb

Product Description

The Weldbend 340-060-000 is a raised face flange designed for industrial use. It features a nominal size of six inches and a thread connection. This flange is made from carbon steel and has a pressure rating of 300 lb. Its reliable construction makes it suitable for various piping applications.

• Nominal Size: Six inches
• Material: Carbon Steel
• Pressure Rating: 740 psig

Product Highlights

This flange is built for durability and strength, designed to handle high pressure in piping systems.

Product Information

Standard Information

• Manufacturer: Weldbend
• Part Number: 340-060-000

Technical Specifications

• Bolt Circle Diameter: 10.62 inches
• Bolt Hole Size: 7/8 inches
• Connection Type: Thread
• Domestic/Import: Domestic
• Hub Diameter: 8.12 inches
• Inside Diameter: 6.75 inches
• Length Through Hub: 2 inches
• Material: Carbon Steel
• Nominal Size: 6 inches
• Number of Bolt Holes: 12
• Pressure Rating: 740 psig
• Temperature Rating: -20 to 100 degrees Fahrenheit
• Type: Raised Face
