Weldbend 14A-080-060 Raised Face Reducing Flange 8 x 6 in

Product Description

The Weldbend 14A-080-060 is a raised face reducing flange designed for a smooth thread connection. This flange measures eight inches by six inches in nominal size and is constructed from durable carbon steel. It operates under a pressure rating of 285 psig and supports pressure class of 150 lb. The temperature range for this product is between negative twenty to one hundred degrees Fahrenheit.

• Thread connection design for secure fittings.
• Constructed from carbon steel for durability.
• Meets ASME and ASTM standards.

Product Highlights

This flange is suitable for various plumbing and industrial applications where a thread connection is needed. Its robust construction ensures compatibility with high pressure and temperature systems.

Product Information

Standard Information

• Brand: Weldbend
• Connection Type: Thread

Technical Specifications

• Material: Carbon Steel
• Nominal Size: 8 x 6 in
• Pressure Rating: 285 psig
• Pressure Class: 150 lb
• Temperature Rating: -20 to 100 deg F
• Type: Raised Face
• Standards/Approvals: ASME SA105/B16.5, ASTM A105
