Weldbend 052-160-080 Pipe Reducing Tee 16 x 16 x 8 in SCH 40/STD

Product Description

The Weldbend Pipe Reducing Tee, MPN 052-160-080, is a vital fitting designed for carbon steel piping systems. This tee fitting allows the connection of three pipes of different sizes with a nominal size of sixteen inches by sixteen inches and eight inches. It is constructed in accordance with the schedule forty standard and features a butt welded end style that ensures a strong and durable joint.

• Nominal Size: 16 x 16 x 8 inches
• Material: Carbon Steel
• Pressure Rating: Up to 820 lbs

Product Highlights

This fitting is suitable for a range of applications in piping systems, particularly in water and gas lines. Designed to withstand temperatures from negative twenty to six hundred fifty degrees Fahrenheit, it performs well under various conditions.

Product Information

Standard Information

• Brand: Weldbend
• Manufacturer: Weldbend

Technical Specifications

• Dimensions: 15-1/4 in ID x 16 in OD x 3/8 in THK Run, 7.981 in ID x 8.62 in OD x 0.322 in THK Branch
• End Style: Butt Welded
• Fitting/Connector Type: Tee
• Nominal Size: 16 x 16 x 8 in
• Pressure Rating: 820 lb
• Schedule Rating: SCH 40/STD
• Temperature Rating: -20 to 650 deg F
