Weksler BY12YPJ4LW Stainless Steel Cased Liquid Filled Pressure Gauge

Product Description

The Weksler BY12YPJ4LW is a stainless steel cased liquid filled pressure gauge designed for accurate pressure readings in various applications. Suitable for use in automated assembly equipment, construction machinery, highway maintenance vehicles, material handling, and metalworking equipment.

• Gauge Type: Liquid
• NPT Male: 1/4 inches
• Mounting Style: Lower Mount

Product Highlights

This gauge comes with a stainless steel case and ring featuring a plastic window, providing durability and readability. The dual scale dials display bar/kPa in blue on the inner scale and psi in black on the outer scale, against a white background, ensuring clarity in pressure measurement.

Product Information

Standard Information

• Brand: Weksler
• Part Number: 101849468

Technical Specifications

• Pressure Range [Max]: 300 psi
• Pressure Range [Min]: 0 psi
• Gauge Pressure Range: 0 to 300 psi
• Face Diameter: 2 1/2 inches
• Socket Material: Brass
• Case Material: Stainless Steel
• Tube Material: Bronze
• Weight: 0.5 LB
