Weksler BY12YPF4LW Stainless Steel Cased Liquid Filled Pressure Gauge (2 1/2 in)

Product Description

The Weksler BY12YPF4LW is a stainless steel cased liquid filled pressure gauge designed for various applications. This product features a two and a half inch face diameter and operates within a pressure range of zero to one hundred psi. It is suitable for automated assembly equipment, construction equipment, and metalworking applications.

• Durable stainless steel construction
• 1/4 NPT lower mount
• Brass socket and bronze tube

Product Highlights

This gauge offers a dual scale dial with clear bar/kPa markings in blue and psi in black against a white background, enhancing readability.

Product Information

Standard Information

• Brand: Weksler
• Part Number: 101799317

Technical Specifications

• Face Diameter: 2 1/2 inches
• Gauge Function: Pressure Gauge
• NPT Male: 1/4 inches
• Pressure Range Maximum: 100 psi
• Socket Material: Brass
• Mounting Style: Lower Mount
• Gauge Type: Liquid
• Pressure Range Minimum: 0 psi
• Tube Material: Bronze
• Gauge Pressure Range: 0 to 100 psi
• Case Material: Stainless Steel
• Weight: 0.5 LB
• EAN or UPC: 759426456624
