Weiss WEISS-TL15-030-8L Pressure Gauge 0-30 Psi

Product Description

The Weiss WEISS-TL15-030-8L is a dual scale pressure gauge rated from 0 to 30 psi, designed for use in HVAC and pneumatic service applications. The gauge features a 1.5-inch drawn steel case finished in black with a push-in polycarbonate window, a 1/8-inch NPT male lower connection, and wetted parts in brass and bronze. Accuracy is rated at plus or minus 2 percent full scale, making it suitable for field pressure checks and system diagnostics. Licensed HVAC technicians and pneumatic system service professionals are the primary installers and users of this gauge.

This gauge is suited for residential and light commercial HVAC systems, pneumatic control circuits, and general-purpose low-pressure monitoring where a compact 1.5-inch dial format is preferred. The bottom connection orientation supports direct panel or line mounting in tight service locations. The dual scale display allows reading in both psi and kPa without conversion. Operating temperature range spans -40 degrees F to 140 degrees F, covering typical field service conditions.

Key Features

• Dual scale display reads in both psi and kPa
• Plus or minus 2 percent full scale accuracy for reliable field readings
• 1/8-inch NPT male lower connection fits standard HVAC and pneumatic fittings
• 1.5-inch drawn steel case with black finish and push-in polycarbonate window
• Wetted parts in brass and bronze for compatibility with common system media
• Wide operating temperature range: -40 degrees F to 140 degrees F

Compatibility

Designed as an OEM-style replacement or service gauge for HVAC and pneumatic systems requiring a 1/8-inch NPT male bottom-connection pressure gauge in the 0 to 30 psi range.

Installation Notes

Installation is typically performed by a licensed HVAC technician or qualified pneumatic systems technician. De-pressurize and isolate the system before removing or installing any pressure gauge. Apply appropriate thread sealant to the NPT connection per applicable codes and do not overtighten, as this can crack the case or damage the socket. Verify the gauge range and media compatibility before placing the gauge into service.

Technical Specifications

• Measurement Range: 0 to 30 psi
• Accuracy: plus or minus 2 percent full scale
• Dial Diameter: 1.5 inches
• Process Connection Size: 1/8 inches NPT Male
• Connection Location: Lower Fitting
• Operating Temperature, Max: 140 degrees F (60 degrees C)
• Operating Temperature, Min: -40 degrees F (-40 degrees C)
• Case Material: Drawn Steel, Black Finished
• Wetted Materials: Brass, Bronze
• Pressure Type: Gauge
• Series: TL15
• Gross Weight: 0.5 pounds
• Country of Origin: United States

Standard Information

• Brand: Weiss
• Manufacturer Part Number: WEISS-TL15-030-8L
