Weiler 36537 Type 1 Cut-off Wheel 3x1/16x3/8 in

Product Description

The WEILER 36537 is a Type 1 resinoid reinforced abrasive cut-off wheel designed for cutting, grinding, and slotting across a wide range of materials. Measuring 3 inches in diameter, 1/16 inches thick, with a 3/8 inches arbor hole, it cuts ferrous and nonferrous metals, plastics, and ceramics. The resinoid bond provides durability and consistent cutting performance under the high RPMs typical of die grinders and air tools. A mandrel kit, sold separately, is required for use with the 3/8 inches arbor configuration. This wheel is suited for tradespeople and fabricators who need a compact, versatile cut-off wheel for tight-access work.

The WEILER 36537 is well suited for auto body repair, die grinding, deburring, weld grinding, and general fabrication tasks. Its compact 3 inches diameter allows it to reach confined areas where larger wheels cannot. Compatible with electric drills, portable grinders, and high-speed air tools, it fits into the standard tool inventory of auto body technicians, welders, pipefitters, and metal fabricators working in both shop and field environments.

Key Features

• Type 1 flat profile for straight cut-off, slotting, and weld grinding applications
• Resinoid reinforced bond for consistent performance at high RPM
• Cuts ferrous metals, nonferrous metals, plastics, and ceramics
• 3/8 inches arbor hole compatible with mandrel kits for use in drills and die grinders
• Compact 3 inches diameter for work in tight or restricted spaces
• Fits electric drills, portable grinders, and high-speed air tools

Compatibility

Designed for use with electric drills, portable grinders, and high-speed air tools equipped with a mandrel sized for a 3/8 inches arbor hole. Mandrel kit sold separately.

Installation Notes

Mount the wheel onto an appropriate mandrel before securing it to the tool spindle. Always verify that the tool RPM rating does not exceed the maximum RPM marked on the wheel before operation. Inspect the wheel for cracks or damage prior to each use and replace if any defects are found. Use appropriate eye protection and guards per ANSI B7.1 safety requirements for abrasive wheel operation.

Technical Specifications

• Wheel Type: Type 1
• Diameter: 3 inches
• Thickness: 1/16 inches
• Arbor Hole: 3/8 inches
• Bond Type: Resinoid reinforced
• Compatible Materials: Ferrous metals, nonferrous metals, plastics, ceramics
• Weight: 0.15 pounds
• UPC: 00012382365370

Standard Information

• Brand: WEILER
• Manufacturer Part Number: 36537
