Weiler 15473 Wheel Brush 2 Inch Crimped Carbon Steel

Product Description

The WEILER 15473 is a 2-inch diameter crimped wire wheel brush designed for aggressive surface conditioning, deburring, cleaning, and blending on metal workpieces. It mounts via a standard arbor hole and runs at up to 20,000 RPM, making it compatible with die grinders, straight grinders, right-angle die grinders, and drill presses. The carbon steel fill wire spans a diameter range of 0.0100 to 0.0199 inches, delivering firm but flexible contact across irregular surfaces. With a face width of 3/8 inches and a trim length of 1/2 inch, this brush suits precision finishing passes where a wider wheel would be impractical.

This wheel brush is suited for use on automated equipment and manual power tools alike. Typical applications include CNC machines, automatic machines, milling operations, and handheld die grinders used by machinists, fabricators, and maintenance technicians. Its compact 2-inch wheel diameter allows access to tight bores, slots, and interior edges where larger brushes cannot reach. No shank is included, so the operator mounts the brush directly through the arbor hole onto the spindle or mandrel of the host tool.

Key Features

• 2-inch outside diameter sized for compact tooling and tight-access work
• Crimped carbon steel fill wire for consistent contact and surface flex
• Rated to 20,000 RPM for use with high-speed die grinders and spindle tools
• Arbor hole mount with no shank — mounts directly to spindle or mandrel
• 3/8-inch face width and 1/2-inch trim length for controlled, precise brush action
• Compatible with CNC machines, automatic machines, drill presses, and die grinders

Compatibility

Rated for use with die grinders, straight grinders, right-angle die grinders, drill presses, drills, milling machines, CNC machines, and automatic machines equipped with a compatible arbor spindle.

Installation Notes

Installation is performed by machinists or tool operators familiar with abrasive accessory mounting procedures. Always confirm the host tool spindle speed does not exceed the 20,000 RPM rating of this brush before use. Power down and isolate the tool completely before mounting or removing the brush from the arbor. Wear appropriate eye protection and follow all applicable ANSI B11 or OSHA standards for abrasive wheel use.
