Weil-Mclain 383900000 Evergreen Evg 220 Condensing Gas Water Boiler 220 MBH

Product Description

The Weil-Mclain 383900000 Evergreen Evg 220 is a residential gas-fired boiler with a 220 MBH AGA input rating. It is designed for hot water systems, with 1-1/2 Inch threaded supply and return connections. This boiler features a stainless steel fire tube heat exchanger and offers a 95 percent AFUE rating. It supports both natural gas and propane fuel types.

• Stainless Steel Fire Tube Heat Exchanger with Non-Metallic Base
• Floor Standing Boiler with Optional Wall Mount Kit
• Modulating Condensing Boiler with 10:1 Turndown

Product Highlights

The Weil-Mclain Evergreen Evg 220 boiler provides efficient heating with its condensing design and versatile mounting options. It is suitable for residential applications.

Product Information

Standard Information

• Brand: WEIL-MCLAIN
• Manufacturer Part Number: 383900000

Technical Specifications

• AFUE Rating: 95 Percent
• AGA Input Rating: 220 MBH
• Air Inlet Connection: 3 or 4 Inch
• Applicable Standard: CSA, ASME H, AHRI, DOE, ANSI Z223.1/21.13, NFPA 54, CAN/CSA B149.1
• Boiler Material: Stainless Steel
• Burner Type: High Grade Stainless Steel, Low NOx
• DOE Heating Capacity: 206 MBH
• GPH Recovery: 10.3 GPM at 40 Deg F
• Gas Connection: 3/4 Inch Threaded
• Gas Type: Natural/Propane
• Ignition Type: Spark
• Inclusions Features: Negative Regulated Combustion, Boiler Circulator, Liquid Propane Conversion Kit, Low Water Cut-Off
• Mounting Type: Floor Standing/Wall Mount
• Net IBR Rating: 179 MBH
• Options: Wall Mount Kit, Concentric Vent Kit, Condensate Neutralizer Kit, Sidewall Vent/Air Termination Kit, Maintenance Kit
• Pressure Rating: 80 PSIG
• Relief Valve Details: Supplied
• Return Connection: 1-1/2 Inch Threaded
• Supply Connection: 1-1/2 Inch Threaded
• Type: Hot Water
• Vent Size: 3 or 4 Inch
• Venting Type: Direct
• Water Content: 4.6 Gallon
• Fuel Type: Natural Gas
• BTU Input: 220000
• BTU Output: 206000
• Annual Fuel Usage Efficiency (AFUE): 95.0
• Domestic Hot Water: No
• Vent Type: Direct Vent
• Building Type: Residential
• Vent Material: Stainless Steel, PolyPro, PVC/CPVC
• Gas Connection (inches): 3/4
• Vent Size (inches): 4
• Heat Exchanger Material: Fire Tube
