Weg ESWC-40T04N4-R34 Electric Starters 20HP

Product Description

The WEG ESWC-40T04N4-R34 is a NEMA 4 enclosed motor starter designed for 20 HP, 460V three-phase applications with 120V control. This full-voltage non-reversing (FVNR) starter features a robust enclosure rated for indoor/outdoor use. It includes a magnetic contactor and thermal overload relay for reliable motor protection.

• ESWC series combination starters come standard with multi-rated enclosures, multi-rated transformers, branch disconnect, short-circuit protection, motor control, overload protection, and control devices.
• Multi-Rated Enclosure Type: 1/3R/4/12
• Multi-Voltage Transformer: primary 208V/230V/460V - secondary 120V

Product Highlights

Suitable for industrial machinery, pumps, and fans in demanding environments.

Product Information

Standard Information

• Brand: WEG
• Manufacturer Part Number: ESWC-40T04N4-R34

Technical Specifications

• Manufacturer Part Number: ESWC-40T04N4-R34
• Manufacturer: WEG Electric
• Product Series: ESWC
• Family Series: WEG Electric Starters, ESWC Series
• Description: Combination Starter, 3PH, 20HP @ 460VAC, 22-32A Range, 480V Pri/120V Sec Transformer, Type 4 Metal Box
• Style: Enclosed
• Industry Standard: NEMA
• Voltage: 120 VAC, 480 VAC
• Nominal Voltage: 120 VAC, 480 VAC
• Current Rating: 40 A
• Overload Type: Bimetallic
• Mounting: Surface
• On/Off Switch: Yes
• Circuit Breaker: Yes
• Approvals: cULus
• HP: 20 HP
• Panel type: Across the line
• Main voltage: 460 V
• Bypass type: None
• Control options: Hand/OFF/Auto Selector Switch
• Enclosure rating: Type 4/12
• Number of phases: 3
• Primary brand: WEG
• Order code / Manufacturer SKU: ESWC-40T04N4-R34
• Manufacturer product status: Commercialized
• UPC code: 7909492677079
• Manufacturer description: Enclosed Starters (ESWC/E/F) - STANDARD PANEL ESWC-40T04N4-R34
