Weg 00336ET3E145JM-W22 3 HP 3600 RPM TEFC 145JM Footed Close Coupled Pump REPLACEMENT 00336EP3E145JM-W22

Product Description

The WEG 00336ET3E145JM-W22 is a 3 HP three-phase JM pump motor designed for high performance and energy efficiency. This motor operates at 3600 RPM with a voltage of 208-230/460 V and is ideal for close-coupled pump applications. Its totally enclosed fan-cooled (TEFC) frame allows operation in moist or dusty environments.

• NEMA Premium Efficiency Level according to NEMA MG-1
• Degree of protection: IP55 – TEFC – Totally enclosed fan cooled
• FC-200 Cast iron frames

Product Highlights

This WEG motor features an improved cooling system, solid feet for reduced vibration, and is suitable for industrial and commercial pumping applications.

Product Information

Standard Information

• Brand: WEG
• Manufacturer Part Number: 00336ET3E145JM-W22
• Country of Origin: Brazil

Technical Specifications

• HP: 3
• RPM: 3460
• Enclosure: TEFC
• Frame: 143/5JM
• Frame Remarks: Footed
• Volts: 208-230/460*
• Phase: 3
• Manufacturer: WEG
• Classification: JM-JP & Jet Pump
• Model: 13469729
• Replaces: 00336EP3E145JM-W22
• Poles: 2
• Frequency: 60 Hz
• Torque: 4.49 lb.ft
• Voltage: 208-230/460 V
• Full Load Amps: 8.20-7.42/3.71 A
• Efficiency (100%): 86.5
• Power factor (100%): 0.86
• Insulation: F
• Noise: 68 dB(A)
• No load current: 3.08/1.54 A
• Locked rotor current (II/In): 8.1
• Application: Closed Coupled
• Frame Size NEMA: 143/5JM
• Mount NEMA: C Face With Base
• Enclosure NEMA: TEFC
• Enclosure IEC: IP55
• Primary brand: WEG
• Order code / Manufacturer SKU: 00336ET3E145JM-W22
• Manufacturer product status: Commercialized
• UPC code: 7909322206455
• Manufacturer description: CLOSE-COUPLED PUMP - TEFC - JM & JP FRAMES - MOTOR 3HP 2P 143/5JM WFF2
• Location of origin: Brazil
