Webstone H-13706HV 1-1/2 through 2 Flange x Rotating Flange Double Flanged Check

Product Description

The Webstone H-13706HV is a uni-flange ball valve designed to isolate a circulator pump. This valve minimizes air entry during pump maintenance. Its design integrates multiple components into a single forged brass body, streamlining installation. This valve is suitable for residential and commercial systems using water, oil, or glycol.

• Isolates circulator pumps without air ingress.
• Constructed from forged brass for durability.
• Features a rotating flange for flexible installation.

Product Highlights

This valve simplifies pump replacement or service while offering exceptional performance.

Product Information

Standard Information

• Brand: Webstone
• MPN: H-13706HV

Technical Specifications

• Type: Isolator Rotating Flange Double Flanged Check
• Material: Brass
• Connection Size: 1-1/2 through 2 inches
• Connection Type: Flange x Rotating Flange
• Flow Rate: 55 to 120 gpm
• Pressure Rating: 150 PSI @ 200°F
• Temperature Rating: 200°F
