Webstone H-10744W 1 inches FIP In-Line Spring Loaded Check Valve

Product Description

The WEBSTONE H-10744W is a 1" FIP In-Line Spring Loaded Check Valve designed to prevent backflow in plumbing and heating systems. Constructed from lead-free Forged DZR Brass, it features a threaded FNPT x FNPT connection and is suitable for residential and commercial applications. This valve can handle a maximum temperature of 250°F and a pressure rating of 200 PSI CWP Max, making it ideal for water, oil, and glycol mix.

• 1" FIP In-Line Spring Loaded Check Valve for reliable backflow prevention.
• Constructed from Lead-Free Forged DZR Brass with a stainless steel spring.
• Rated for a maximum temperature of 250°F and 200 PSI CWP Max pressure.

Product Highlights

Lead-free DZR brass check valve for plumbing and heating systems, preventing backflow with a 250°F max temperature.

Product Information

Standard Information

• Brand: WEBSTONE
• Manufacturer Part Number: H-10744W
• Country of Origin: China

Technical Specifications

• Nominal Pipe Size: 1 inch x 1 inch
• Connection Type: FNPT x FNPT
• Connection Method: Threaded
• Lead Free: Yes
• Max Temperature: 250 F Max
• Body Material: Lead-Free DZR Forged Brass
• Certifications: NSF/ANSI 61 & 372
• Valve Type: Spring Check Valve
• Weight: 322.05 g
• Pressure Rating: 200 PSI CWP Max
• Cv Coefficient: 9.20
• Cracking Pressure: 0.50 psi
• Stem Material: Brass
• Spring Material: Stainless Steel
• Gasket Material: FKM
• End Cap Material: Brass
• Diameter: 1.79 inch
• Length: 2.75 inch
• Model: THD-107XW
• Series: H-107X
• UPC: 018394015463
• Width: 1.79 inch
• Height: 1.79 inch
• Country of Origin: CN
• Potable Water Code: LL Compliant NSF/ANSI 372
• Application: Commercial & Residential Plumbing, Heating
