Webstone H-10743W Threaded Spring Loaded Check Valve 3/4 Lead Free

Product Description

The Webstone H-10743W is a three-fourths inch threaded spring loaded check valve designed for flow control in plumbing and heating systems. It is made from lead-free brass and provides FNPT x FNPT connections, suitable for water, oil, and glycol mixtures. This valve is versatile for residential and commercial applications.

• Connection: 3/4 inch FNPT x FNPT
• Temperature Rating: 250 degrees Fahrenheit
• Durable Construction: Brass with stainless steel spring

Product Highlights

The forged DZR brass design ensures long-lasting performance in various media applications, including gas, oil, and water.

Product Information

Standard Information

• Brand: Webstone
• MPN: H-10743W

Technical Specifications

• Connection Method: Threaded
• Size: 3/4 inch
• Lead Free: Yes
• Max Temperature: 250 degrees Fahrenheit
• Material: Brass
• Pressure Rating: 200 psi
• Cv Coefficient: 6.65
• Cracking Pressure: 0.75 psi
• Body Material: Brass
• Spring Material: Stainless Steel
• Gasket Material: FKM
• Actuator Type: Spring
• Inlet to Outlet Length: 2.31 inches
• Nominal Size: 3/4 inch
• Domestic/Import: Import
• UPC Code: 018394015456
