Weatherking WA13NY42AJ1NA 3.5Ton 13SEER2 Condenser - 3/8l 7/8s

Product Description

The WeatherKing WA13NY42AJ1NA 3.5Ton 13SEER2 Condenser utilizes R454B refrigerant and is designed for HVAC systems. This condenser features a single-stage compressor and operates at 208/230V. It is suitable for residential or commercial applications requiring efficient cooling. The unit is A2L compatible and has a decibel rating of 68 dB.

• A2L Compatible
• Refrigerant: R-454B
• Compressor Type: Scroll

Product Highlights

The WeatherKing WA13NY42AJ1NA condenser provides efficient cooling with a focus on safety and environmental considerations, utilizing R-454B refrigerant and A2L compatibility.

Product Information

Standard Information

• Brand: WeatherKing
• Manufacturer Part Number: WA13NY42AJ1NA

Technical Specifications

• SKU: 116020
• Product Type: Simple product
• UOM: ea
• Type: Condenser
• ABRPN: WA13NY42AJ1NA
• Series: WA13NY
• Brand: Weatherking
• Product Status: Stock
• Refrigerant: R454B
• A2L Compatible: Yes
• BTU: 42000
• BTU Cooling Rating: 40000 Btu/h
• CFM: 2758 ft�_/min
• Collection: Endeavor� Line
• Communicating: Non-Communicating
• Compressor Stages: Single Stage
• Compressor Type: Scroll
• Decibel Rating (dB): 68 dB
• Depth: 33-33/50 in
• Height: 27-17/100 in
• Horsepower: 1/5 hp
• Liquid Line (OD): 3/8 in
• MBH: 42
• Phase: Single Phase
• Power Source: Electric
• RPM: 825
• SEER2: 13.4
• SEER2 Range: 13.4 - 13.7
• Sound Blanket: No
• Suction Line (OD): 7/8 in
• Tonnage: 3.5 Ton
• UL Listed: Yes
• Volts: 208/230V
• Watts: 145 W
• Width: 33-33/50 in
• Cooling Efficiency: 13.4 SEER2 / 9 EER2
• Nominal Sizes: 1.5 to 5 Tons [TBD kW]
• Cooling Capacities: 17.1 to 55.5 kBTU
• Sound Ranking: As low as 68 dB
• EcoNet� Enabled: No
• Condenser Coil Type: 7mm
• Nominal Capacity: 42000 Btu/h
• Nominal Capacity kW: 12.31 kW
• Nominal Capacity TR: 3.5 TR
• Refrigerant Furnished oz.: 112
• Sound Level: 68 dB
• Voltage: 208 to 230 V
• Number of Phases: 1
• Frequency: 60 Hz
• Maximum Overcurrent Protection: 35 A
• Minimum Circuit Ampacity: 23 A
• Compressor - Rated Load Amps: 17.3 A
• Compressor - Locked Rotor Amps: 123.0 A
• Condenser Fan Motor - Full Load Amps: 0.80 A
• Condenser Fan Motor - Locked Rotor Amps: 1.5 A
• Net Face Area - Outer Coil: 14.3 ft�_
• Net Face Area - Inner Coil: 13.9 ft�_
• Tube Diameter: 0.276 in
• Number of Rows: 2
• Fins per Inch: 24
• Outdoor Fan Diameter: 24 in
• Number of Blades: 2
• Motor HP: 1/6 hp
• Total Capacity: 40000 Btu/h
• Total Capacity kW: 11.7 kW
• Net Sensible Capacity: 30700 Btu/h
• Net Sensible Capacity kW: 9 kW
• Net Latent Capacity: 9300 Btu/h
• Net Latent Capacity kW: 2.7 kW
• EER2: 9.0
• Indoor CFM: 1300 ft�_/min
• Indoor CFM L/s: 613.5 L/s
• Liquid Line O.D.: 3/8 in
• Suction Line O.D.: 7/8 in
