Wavenet whvs1006 Passive Video Splitter 1x6 2 Ghz

Product Description

The WAVENET whvs1006 is a passive 6-port video splitter rated to 2 GHz, designed to distribute a single coaxial video signal to six output locations without active amplification. Built with a plastic mounting bracket for secure installation, it suits residential and light commercial signal distribution applications. The passive design requires no external power source, making it straightforward to deploy in structured wiring enclosures, utility rooms, or wall cavities. Low-voltage installers, cable technicians, and AV integrators are the typical trades working with this device.

The whvs1006 is suited for residential multi-room video distribution systems where one incoming coaxial signal needs to feed up to six individual outlets or devices. Its 2 GHz bandwidth supports standard cable television, satellite, and broadband RF signals across the distribution run. The included plastic bracket simplifies mounting inside structured wiring panels or enclosures commonly found in new construction and retrofit installations.

Key Features

• Passive design requires no external power source
• 2 GHz bandwidth supports cable TV, satellite, and broadband RF signals
• Six output ports distribute one input signal to six locations
• Includes plastic mounting bracket for panel or enclosure installation
• Compact form factor suitable for structured wiring enclosures

Compatibility

Designed as an OEM-style replacement or standard installation component for residential and light commercial coaxial video distribution systems using standard F-connector coaxial cabling.

Installation Notes

Installation is typically performed by low-voltage technicians or AV integrators. Ensure the incoming coaxial signal source is disconnected before making any connections. Use a torque wrench or hand-tighten F-connectors to a snug fit to avoid signal loss at connection points. Passive splitters introduce insertion loss across all ports, so verify signal levels at the source are adequate to support a 6-way split before installation.

Technical Specifications

• Number of Ports: 6 output ports
• Frequency Range: 2 GHz
• Amplification: Passive (no power required)
• Bracket Material: Plastic
• Configuration: 1 input x 6 outputs

Standard Information

• Brand: WAVENET
• Manufacturer Part Number: whvs1006
