Wavenet CAT6-550-RISER-1000-BLUE Cat6-550 Riser 550 MHz (1000 ft) 146862

Product Description

Wavenet CAT6-550-RISER-1000-BLUE is a Cat6 riser cable rated to 550 MHz, featuring four twisted pairs of 23 AWG solid conductors in an unshielded (UTP) construction with a riser-rated (CMR) jacket. The cable is supplied in a 1000 ft box and is intended for network installations, CCTV, access control and other vertical riser wiring applications where riser-rated jacketing is required.

• 550 MHz Cat6 performance with 4 twisted pairs and 23 AWG solid conductors
• Unshielded (UTP) construction with riser-rated (CMR) jacket for vertical riser spaces
• Supplied in a 1000 ft box for network, CCTV and access control wiring

Product Highlights

Cat6 550 MHz; 23 AWG solid; 4 twisted pairs; unshielded UTP; riser-rated (CMR) jacket; 1000 ft box

Product Information

Standard Information

• Brand: WAVENET
• Manufacturer Part Number: CAT6-550-RISER-1000-BLUE

Technical Specifications

• Manufacturer Part Number: CAT6-550-RISER-1000-BLUE
• Brand: Wavenet
• Alternate Part Numbers: 146862, 77150, CAT6-550-1000-BLUE, CAT65501000BLUE, CAT6550RISER1000BLUE, CAT6E-550-RISER-1000-BLUE, CAT6E550RISER1000BLUE, REM6A234UTPRENHM30, WRECAT6-550-RISER-1000-BLUE
• Conductor: 23 AWG (solid)
• Pairs: 4 twisted pairs
• Shielding: Unshielded (UTP)
• Jacket Type: Riser (CMR)
• Bandwidth: 550 MHz
• Length: 1000 ft
• Cable Type: CAT6, Non-Plenum (CMR)
• Certifications: NEC 800-UL Riser CMR; ETL
• Category: Access control; CCTV; Wire & Cable; Wire & Power Supplies
• Box dimensions (H x L x W): 8.46 x 16.34 x 16.14
