WATTS W-0856809 1/2 in. Lead Free Flow Measurement Valve with Solder Connections

Product Description

The WATTS W-0856809 is a flow measurement valve with a half-inch lead-free brass construction. It is suitable for low to medium flow rate HVAC units and domestic water recirculation systems. The design allows bi-directional flow and features a positive shutoff mechanism. This valve has a ball-type mechanism, an extended throttling range, and a clear indicator plate for precise flow measurement.

• Lead-free body for safe water use
• Bi-directional flow with positive shutoff
• Includes memory device and integral drain ports

Product Highlights

WATTS W-0856809 valve is efficient for HVAC units and provides reliable performance. Ideal for plumbers and HVAC technicians, it enhances system control and maintenance.

Product Information

Standard Information

• Brand: Watts
• Part Number: W-0856809

Technical Specifications

• Valve Style: Ball
• Body Material: Lead Free Brass
• Inlet Connection Size: 1/2 in.
• Outlet Connection Size: 1/2 in.
• Max Working Pressure: 125 psi
• Max Temperature: 200°F
• Connection Type: Solder
