Watts SG-050 1/2, MPT, Copper, Piston, Water Hammer Arrestor

Product Description

The Watts SG-050 is a water hammer arrestor designed to reduce the noise and shock in plumbing systems caused by sudden changes in water flow. This model features a piston type mechanism with a half-inch male threaded inlet connection. The body is constructed from copper, ensuring durability and reliable performance. It is suitable for both domestic and commercial applications.

• Inlet size of half an inch
• Pressure rating of 150 PSI
• Temperature rating from 33 to 180 degrees Fahrenheit

Product Highlights

Ideal for preventing water hammer in piping systems.

Product Information

Standard Information

• Manufacturer: Watts
• UPC: 000003051160

Technical Specifications

• Type: Piston
• Body Material: Copper
• Spherical Piston Material: Brass
• Overall Height: 4-7/8 inches
• Top Shape: Round
• Top Size: 1-7/16 inches diameter
• Inlet Connection: Male Threaded
• Fixture Unit Rating: 1-11
• Applicable Standard: ASSE 1010, PDI WH201, UPC
• Inclusions/Features: EPDM O-Ring
• Product ID: 29230
