Watts Regulator Company 0275022 1 174A-040 Pressure Relief Valve 40 psi

Product Description

The Watts Regulator Company 0275022 is a pressure relief valve designed for hot water heating boilers. This valve features a bronze body and nominal size of one inch. With a pressure rating of forty psi and a temperature rating of two hundred fifty degrees Fahrenheit, it meets industry standards for safety and performance.

• Bronze material ensures durability and resistance to corrosion
• Designed for emergency safety relief, this valve should be tripped at least once a year
• Non-mechanical seat-to-disc alignment prevents sticking or freezing

Product Highlights

This valve offers important protection for hot water heating systems, guarding against excessive pressure buildup. The design incorporates a water seal that isolates spring working parts from water, enhancing reliability.

Product Information

Standard Information

• Manufacturer: Watts Regulator Company
• UPC: 098268013337

Technical Specifications

• Body Material: Bronze
• Dimensions: 3 inches L x 5-3/4 inches H
• End Style: FNPT
• Media: Water
• Nominal Size: 1 inch
• Pressure Rating: 40 psi
• Series: 174A
• Temperature Rating: 250 degrees F
