Watts LFUSG-B-SC M2 - Thermostatic Mixing Valve - 3/4 in - Lead-Free

Product Description

The Watts LFUSG-B-SC M2 is a thermostatic mixing valve designed for safe and efficient temperature control. This lead-free valve is used in both commercial and residential settings to manage hot water temperature, reducing the risk of scalding. It integrates into kitchen and bath installations, ensuring comfortable and safe water delivery.

• Lead-free brass body with compression fittings.
• Temperature adjustable from eighty to one hundred twenty degrees Fahrenheit.
• Built-in check valves to prevent water cross-flow.

Product Highlights

This thermostatic mixing valve provides reliable flow rates and temperature control with significant pressure handling capabilities.

Product Information

Standard Information

• Brand: Watts
• Part Number: LFUSG-B-SC M2

Technical Specifications

• Connection Size: 3/4 in
• Connection Type: Compression
• Material: Brass
• Pressure Rating: 30 - 150 psi
• Temperature Rating: 80 - 120 deg F
• Flow Rate: 0.25 - 2.5 gpm
• Standard Certifications: ASSE 1070, CSA B125.3, cUPC, IAPMO listed, ANSI/NSF 61 and 372 certified.
• Applications: Suitable for residential and commercial use.
