Watts F153614 40L-3 Bronze Automatic Reseating Temperature and Pressure Relief Valve 3/4 IN

Product Description

The Watts F153614 model 40L-3 is a temperature and pressure relief valve designed for use in hot water systems. This valve features a three-fourth inch NPT male inlet and a three-fourth inch NPT female outlet. Constructed from bronze, it has a pressure relief setting of one hundred fifty psi and a temperature relief setting of two hundred ten degrees Fahrenheit. This valve is suitable for installation directly into tank tappings, especially in commercial settings, to protect hot water tanks and heaters.

• Includes a flood sensor utilizing SentryPlus Alert technology
• Activation kit required to activate the flood sensor
• Bronze construction for durability

Product Highlights

This valve effectively protects against excessive pressure and temperature in hot water systems.

Product Information

Standard Information

• Brand: Watts
• Model: 40L-3

Technical Specifications

• Body Material: Bronze
• Inlet Connection Size: 3/4 IN
• Inlet Connection Type: Male Threaded
• Outlet Connection Size: 3/4 IN
• Outlet Connection Type: Female Threaded
• Pressure Relief Setting: 150 psi
• Maximum Temperature: 210 degrees Fahrenheit
• Valve Application: Hot Water
• Valve Size: 3/4 IN
• Piping Configuration: Angle
• BTU Rating: 1,437,600 BTU
• Actuator Type: Test Lever
• Media: Water
