Watts F121594 LFN241X-8 1 1/4 in 125 psi 210 degree F

Product Description

The WATTS F121594 is a lead free automatic reseating temperature and pressure relief valve, featuring a 1 1/4 inch NPT male inlet and 1 inch NPT female outlet. Designed for hot water supply tanks and heaters, it has a pressure relief setpoint of 125 psi and a temperature relief setpoint of 210 degrees F. An 8 inch stainless steel extension thermostat and a discharge line flood sensor are included for enhanced safety and monitoring.

• Features a flood sensor with SentryPlus Alert technology to detect excessive water discharges from the relief valve
• Lead free copper silicon alloy body ensures compliance and durability
• Tamper resistant bonnet screws provide added security

Product Highlights

Includes a nonrestrictive discharge drain line flood sensor with SentryPlus Alert technology for detecting excessive water discharges.

Product Information

Standard Information

• Brand: WATTS
• Manufacturer Part Number: F121594

Technical Specifications

• Body Material: Lead Free Copper Silicon Alloy
• Inlet Connection Size: 1 1/4 IN
• Inlet Connection Type: Male Threaded
• Inlet Thread Type: NPTF
• Lead Free: Yes
• Maximum Working Pressure: 93 PSI
• Outlet Connection Type: Female Threaded
• Outlet Thread Type: NPTF
• Pressure Relief Setting: 125 PSI
• Protection Type: Temperature And Pressure
• Series: LFN240
• Model: LFN241X-8
• Temperature Relief Setting: 210 Fahrenheit
• Thermostat Material: Stainless Steel
• Thermostat Probe Length: 8 IN
