Watts Brass Tubular PL-3042 Quick Connect Straight Valve

Product Description

The WATTS BRASS TUBULAR PL-3042 is a quick connect straight valve designed for use with 3/8-inch outside diameter poly or soft copper tubing. One end accepts a push-in quick connect fitting for fast, tool-free tube insertion, while the other end terminates in a 3/8-inch male pipe thread (MPT) for standard threaded connection. This valve is intended for low-pressure water supply applications where a reliable shutoff point is needed. It is sold in a pack of 5 units, making it practical for multi-fixture installs or service stock. Licensed plumbers and pipefitters are the typical installers for this type of valve in residential and light commercial settings.

This valve suits applications where flexible poly tubing or soft copper runs are connected to a threaded port, such as ice maker supply lines, water filtration systems, and similar low-pressure service lines. It is not rated for use with steel tubing and must not be used in concealed installations where access for inspection or servicing is restricted. The quick connect end simplifies connections in tight spaces without the need for compression fittings or flare tools.

Key Features

• Quick connect inlet accepts 3/8-inch OD poly or soft copper tubing without additional fittings
• 3/8-inch male pipe thread outlet for standard threaded port connections
• Straight valve configuration provides in-line shutoff capability
• Not suitable for steel tubing or concealed installations
• Sold in a pack of 5 units for multi-unit service or inventory stocking

Compatibility

Designed for use with 3/8-inch outside diameter poly or soft copper tubing connecting to a 3/8-inch male pipe thread port. Not compatible with steel tubing. Not approved for concealed installations.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and IPC guidelines. Shut off the water supply and relieve line pressure before installing or removing this valve. Ensure tubing is cut cleanly and squarely before inserting into the quick connect end to achieve a proper seal. Do not use this valve in wall, ceiling, or floor cavities where future access would not be available.

WARNING: This product can expose you to chemicals including lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
