Product Description
The WATTS LFFBV-3C-M1 is a 2-1/2" lead-free, 2-piece, full port brass ball valve designed for commercial and industrial applications, suitable for a full range of liquids and gases. Constructed with a fluorocarbon elastomer stem O-ring to prevent stem leaks, it also features a bottom-loaded blowout-proof stem and an adjustable stem packing gland.
- Lead-Free forged copper silicon alloy body and adapter
- Machined chrome-plated Lead-Free brass ball
- Certified to NSF/ANSI standard 61/8
Product Highlights
This Watts ball valve is ideal for controlling the flow of liquids and gases in various plumbing and industrial settings.
Product Information
Standard Information
-
Brand: WATTS
-
Manufacturer Part Number: 88005697
-
Country of Origin: China
Technical Specifications
-
WOG [Features]: 400
-
Size [Features]: 2-1/2"
-
Features [Features]: Standard
-
Material [Features]: Brass
-
Lead Free [Features]: Yes
-
Port Type [Features]: Full Port
-
Thread Type [Features]: Female
-
Handle Style [Features]: Lever
-
Connection Type [Features]: FNPT x FNPT
-
Connection Method [Features]: Threaded
-
Max Pressure (PSI) [Features]: 125
-
Valve Construction [Features]: 2 piece
-
Brand: Watts
-
Mfr_No: 88005697
-
Size: 2-1/2"
-
WOG: 400
-
Max Pressure (PSI): 125
-
Material: Brass, Chrome-Plated Brass, Copper Silicon Alloy, Steel
-
Connection: 2 1/2"
-
Pressure Rating: 125 - 400 PSI
-
Temperature Rating: 0 - 400 Degrees F
-
Type: Ball Valves
-
Actuation: No
-
Ball Material: Chrome Plated Brass
-
Body Finish: Brass
-
Body Material: Lead Free Copper Silicon Alloy
-
Control Type: Lever Handle
-
Inlet Connection Size: 2 1/2 IN
-
Inlet Connection Size-Metric: 65 MM
-
Inlet Connection Type: Female Threaded
-
Inlet Thread Type: NPT
-
Maximum Temperature-Fahrenheit: 400
-
Minimum Temperature - Celsius: -18.00
-
Minimum Temperature-Fahrenheit: 0
-
Outlet Connection Size: 2 1/2 IN
-
Outlet Connection Type: Female Threaded
-
Outlet Thread Type: NPT
-
Part Number: 88005697
-
Seat Material: Virgin PTFE
-
Series: LFFBV-3C-M1
-
Stem Packing Material: PTFE
-
Stem Shaft Material: Brass
-
Stem Type: Bottom Loaded Blowout Proof
-
Thrust Washer Material: PTFE
-
Valve Style: 2-piece
-
WOG Rating: 400 PSI
-
Configuration: 2-Piece
-
Handle Material: Steel
-
Inlet to Outlet Length: 5-1/2 in
-
Lead-Free/Contains Lead: Lead-Free
-
Media: Gas, Liquid, Water
-
Nominal Size: 2-1/2 INCH X 2-1/2 INCH
-
Operator Type: Lever Handle
-
Packing Material: PTFE
-
Seal Material: PTFE
-
Softgoods Material: PTFE/Virgin PTFE
-
Stem Material: Brass
-
Top to Inlet Center: 4-1/16 in
-
Trim Material: Brass/Virgin PTFE
-
Brand Name: Watts
-
Mfg Part#: 88005697
-
Applicable Standard: MSS-SP-110
-
Inclusions/Features: BOTTOM LOADED BLOWOUT PROOF STEM
-
End Connection: FEMALE THREADED X FEMALE THREADED
-
Actuation Type: LEVER HANDLE
-
Model: LFFBV-3C-M1
-
Manufacturer: Watts
