WATTS 501203 Little Giant Submersible Dual Purpose Pump

Product Description

The WATTS 501203 Little Giant submersible pump is designed for versatile applications in both residential and commercial settings. The pump can operate as a submersible or inline unit, making it suitable for various liquid transfer tasks. It features a 1/4 MNPT discharge and achieves a maximum head of 7.4 feet, facilitating efficient water movement.

• Suitable for submersible or inline use
• Equipped with thermal overload protection
• Constructed from epoxy-coated die-cast aluminum

Product Highlights

This pump is efficient and reliable, making it ideal for tasks that involve moving water in diverse environments.

Product Information

Standard Information

• Brand: WATTS
• MPN: 501203

Technical Specifications

• Horsepower: 1/150 HP
• Input Voltage: 115 VAC
• Frequency: 60 Hz
• Power Consumption: 70 W
• Output Current: 1.1 A
• Maximum Flow Rate: 205 GPH
• Maximum Head: 7.4 ft
• Maximum Fluid Temperature: 120 °F
• Cord Length: 6 ft
• Discharge Port: 1/4 inch MNPT
• Inlet Port: 1/2 inch FNPT and 1/4 inch FNPT
• Impeller Material: Nylon
• Shaft Seal Material: Nitrile Rubber
• Housing Material: Epoxy coated cast aluminum
• Discharge Type: Threaded - MNPT
• Suction Type: Threaded - NPT
• Discharge Size: 0.5
• Suction Size: 0.25
• Dimensions: 4.6 x 4.1 x 4 inches
• Weight: 3 lb
• Certifications: CSA/UL
• Phase: 1
