Watts 3510-0808 AquaLock Plastic Series Female Adapter 3/8 inches CTS x 1/2 inches NPS

WATTS
Brand: WATTS
SKU: 3510-0808
Availability: In Stock

Ships same day if ordered by 12 pm

$14.99
$14.99
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

Watts 3510-0808 is a polysulfone AquaLock female adapter that connects 3/8" CTS tubing to 1/2" NPS threads. The push-to-connect fitting uses an O-ring guide and a swivel nut with NPS straight threads and cone seal to provide a zero-leak connection and hand-tighten installation. It is compatible with copper, CPVC, and PEX (LDPE, MDPE, HDPE), permits tubing rotation under pressure, and is suitable for hot and cold water and behind-the-wall applications.

  • Push-to-connect 3/8" CTS inlet to 1/2" NPS female outlet with swivel nut and cone seal
  • Polysulfone construction with O-ring guide for a zero-leak connection; reusable
  • Compatible with copper, CPVC, PEX (LDPE, MDPE, HDPE); rotates under pressure for dynamic applications

Product Highlights

Polysulfone push-to-connect female adapter for 3/8" CTS to 1/2" NPS with O-ring guide and swivel nut

Product Information

Standard Information

  • Brand: WATTS
  • Manufacturer Part Number: 3510-0808
  • Country of Origin: Canada
Technical Specifications
Brand
Watts
MPN
3510-0808
Series
AquaLock Plastic Series
Size
3/8" CTS x 1/2" NPS
Material
Polysulfone (high-performance thermoplastic, lead-free)
Connection Type
Push-to-connect female adapter with swivel nut
Inlet Connection
3/8" CTS (tubing)
Outlet Connection
1/2" NPS (female threads)
Seal / O-ring
O-ring guide (EPDM listed by alternate sources)
Compatible Pipe / Tubing
Copper, CPVC, PEX (LDPE, MDPE, HDPE), CTS-rated pipe
Installation
Tool-free; hand-tighten onto threads; no tube inserts or thread sealant required
Reusable
Yes
Application / Use
Hot and cold water; behind-the-wall installations; vibrating and dynamic applications
Approvals / Standards
FDA, ANSI/NSF-61, NSF-14, CSA B1375, ASTM F877, IAPMO ASSE 1061-2006
Maximum Working Pressure
250 psi
Maximum Working Temperature
75 F (24 C) [QUESTIONABLE - see notes]
Minimum Operating Temperature
33 F (0.56 C)
Country of Origin
Made in Canada
UPC
098268040913
Number of Items
1
Package Weight
21 g
Includes
O-ring
