Watts 123475 3/4 Inch Lead Free Full Port Ball Valve

Product Description

The WATTS 123475 is a 3/4-inch IPS two-piece full port ball valve built for commercial and industrial fluid and gas control. The lead free brass body meets lead free compliance standards for potable water systems. A chrome plated lead free brass ball, virgin PTFE seat, and fluorocarbon elastomer stem O-ring work together to deliver reliable shutoff with minimal leak risk. The bottom-loaded blowout-proof stem adds a critical layer of pressure safety. This valve is rated at 600 psi WOG and 150 psi WSP. Licensed plumbers and pipefitters are the primary installers for this type of valve in commercial mechanical systems.

This ball valve is suited for commercial and industrial piping systems handling a full range of liquids and gases, including water, oil, and gas service. The full port design minimizes flow restriction, making it appropriate for high-demand lines where pressure drop must be controlled. The included cap and chain protect the end connection when the valve is used in a partially completed installation or maintained in a serviceable configuration. The steel handle provides firm manual operation in tight mechanical spaces.

Key Features

• Lead free brass body and chrome plated lead free brass ball meet lead free compliance requirements
• Full port design for unrestricted flow through 3/4-inch IPS piping
• Bottom-loaded blowout-proof stem for added pressure safety
• Virgin PTFE seat and thrust washer for durable, low-friction shutoff
• Fluorocarbon elastomer stem O-ring prevents stem leaks under pressure
• Adjustable stem packing gland and stem packing nut allow field serviceability
• Cap and chain included to protect open end connections

Compatibility

Designed for use in 3/4-inch IPS commercial and industrial piping systems handling water, oil, and gas service where lead free construction is required.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing codes and IFGC requirements for gas service applications. Shut off and depressurize the supply line fully before removing any existing valve or fitting. Verify thread engagement and apply appropriate thread sealant compatible with the service medium before pressurizing. Do not exceed the rated 600 psi WOG or 150 psi WSP limits for the installed service condition.

Technical Specifications

• Connection Size: 3/4 inches IPS
• Valve Configuration: Two-Piece Full Port
• Pressure Rating (WOG): 600 psi
• Pressure Rating (WSP): 150 psi
• Body Material: Lead Free Brass
• Ball Material: Chrome Plated Lead Free Brass
• Seat Material: Virgin PTFE
• Stem O-Ring Material: Fluorocarbon Elastomer
• Handle Material: Steel
• Lead Free Compliant: Yes

Standard Information

• Brand: WATTS
• Manufacturer Part Number: 123475
