Watts 0388016 Freeze Resistant Pressure Vacuum Breaker With Lever Handle, 1-1/4 in Nominal, FNPT End Style, Bronze Body

Product Description

The Watts 0388016 is a freeze resistant pressure vacuum breaker designed to prevent the reverse flow of contaminated water into the potable water supply. This unit features a bronze body and is engineered for durability and reliability.

• Freeze resistant design for harsh conditions
• Suitable for continuous pressure applications in health hazard zones
• Easy maintenance with a replaceable plastic seat

Product Highlights

This vacuum breaker is ideal for irrigation systems and industrial processes exposed to freezing temperatures. It includes a built-in relief valve to protect against ice damage.

Product Information

Standard Information

• MPN: 0388016
• Brand: Watts

Technical Specifications

• Application: Health Hazard
• Body Material: Bronze
• Dimensions: 8-7/8 in L x 9 in H
• Domestic/Import: Domestic
• End Style: FNPT
• Flow Rate: 7.5 fps
• Pressure Rating: 150 psi
• Temperature Rating: 33 to 140 deg F
• Series: 800M4FR
• Standards/Approvals: ANSI/ASSE 1020, IAPMO/UPC Listed
