Watts 0066132 Series LL100XL 3/4 in Bronze MNPT x FNPT 150# 210 Relief Valve

Product Description

The Watts 0066132 is a self-closing temperature and pressure relief valve. This valve is designed for water heater applications where safety and efficiency are essential. It ensures automatic temperature and pressure protection for hot water supply tanks and heaters up to one hundred five thousand BTUs per hour.

• Self-closing functionality provides enhanced automation
• Brass body construction ensures durability
• Extended inlet shank accommodates thick insulation

Product Highlights

This product features a unique thermostat with a special thermo-bonded coating that provides reliable performance over time. The temperature rating is two hundred ten degrees Fahrenheit, and the pressure relief range is between seventy-five to one hundred fifty psi, making it suitable for various applications.

Product Information

Standard Information

• Brand: Watts
• MPN: 0066132

Technical Specifications

• Body Material: Brass
• Connection Size: 3/4 in
• Connection Type: MNPT x FNPT
• Pressure Rating: 150 psi
• Temperature Rating: 210 deg F
• Probe Length: 2-1/2 in
• Actuator Type: Test Lever
• Series: LL100XL
