Watts 0037105 Series WFT 1 in. 353F 125 psi Steam Trap

Product Description

The Watts Series WFT steam trap, model 0037105, is designed to effectively manage condensate removal in steam applications. This device features a reliable H-pattern for efficiency, ideal for use in heating systems.

• Constructed with durable cast iron for longevity.
• Universal 4-port design allows for versatile installation options.
• Stainless steel components minimize erosion and corrosion.

Product Highlights

This steam trap operates at a maximum pressure of 125 psi and a temperature of 353 degrees Fahrenheit. It is built for continuous air venting, making it suitable for various steam applications.

Product Information

Standard Information

• Brand: Watts
• MPN: 0037105

Technical Specifications

• Body Material: Cast Iron
• Nominal Size: 1 inch
• Pressure Rating: 125 psi
• Temperature Rating: 353 degrees Fahrenheit
• Orifice Size: 0.218 inches
• Dimensions: 5-3/4 inches height, 6-1/4 inches length
• Mounting Type: H-Pattern, Same Side
