Waterway Plastics 640-1361V Waterway Plastics 32-Inch Concrete Diamond Strip Channel Drain Black

Product Description

The Waterway Plastics 640-1361V is a 32-inch concrete diamond strip channel drain designed to effectively manage water around pools and outdoor areas. Constructed from corrosion-resistant materials, this drain features a diamond pattern for optimal water collection. It can be adapted for either single or multiple drain setups.

• Includes a grate, plugs, a 3-port sump, and stainless steel screws for installation.
• Open area measures 37.7 square inches for efficient water flow.
• Capable of handling a floor flow rate of 280 gpm at 3.75 ft/sec and up to 320 gpm at 4.29 ft/sec.

Product Highlights

The drain's design ensures that water is effectively collected while remaining durable for outdoor use.

Product Information

Standard Information

• Brand: Waterway Plastics
• MPN: 640-1361V

Technical Specifications

• Dimensions: 32.710 inches length x 3.850 inches width x 5.725 inches height
• Open Area: 37.7 square inches
• Floor Flow Rate: 280 gpm at 3.75 ft/sec, 320 gpm at 4.29 ft/sec
• Wall Flow Rate: 216 gpm at 2.89 ft/sec, 240 gpm at 3.22 ft/sec
• Shipping Dimensions: 33.38 x 8.00 x 8.00
• Color: Black
• Weight: 50 lbs
• Department: Whitegoods | Flow fittings
