Waterway Plastics 215-8200 6-Inch Ultra Suction Wall Fitting with 2-Inch Equalizer

Product Description

The Waterway Plastics 215-8200 is a wall fitting made for ultra suction systems measuring six inches. It features a sumpless design, eliminating the need for a separate sump body. This fitting works with various pool types, including Gunite, Fiberglass, Tile, and Steel Pools & Spas.

• Sumpless design removes the need for a separate sump body
• Compatible with multiple pool types
• Includes various PVC wall fitting adapters

Product Highlights

The Waterway Plastics 215-8200 fitting provides a wall flow rate of 191 GPM when paired with compatible models. It supports a flow rate of 47 GPM at a rate of 1.5 ft/sec. The use of NSF-rated PVC ensures compatibility with standard PVC cements.

Product Information

Standard Information

• Brand: Waterway Plastics
• Item: Equalizer Wall Fitting

Technical Specifications

• Total Open Area: 10.2 sq. in.
• Wall Flow Rate: 191 GPM with specified models
• Flow Rate at 1.5 ft/sec: 47 GPM
• Connection Size: 2 inches
• For Use With: 6-inch Ultra Suction
