Walter Surface Technologies 15L706 Type 29 Grinding Wheel

Product Description

The WALTER SURFACE TECHNOLOGIES 15L706 is a Type 29 depressed center grinding wheel designed for aggressive material removal on angle grinders. It measures 7 inches in diameter with a 7/8 inch arbor hole and uses an aluminum oxide abrasive at 60 grit, a medium grade suited for fast stock removal. Rated to 8600 RPM maximum, this wheel handles demanding grinding tasks on metal and related materials. It is installed by fabricators, ironworkers, pipefitters, and maintenance technicians who require consistent cutting action across multiple substrate types.

This grinding wheel is intended for use with angle grinders in fabrication shops, construction sites, and industrial maintenance settings. It performs on steel, stainless steel, aluminum, and other non-ferrous metals, making it a versatile choice when a single wheel must address varied material types. The Type 29 conical profile provides an aggressive cutting angle that increases contact surface area compared to a flat Type 1 wheel, which aids in blending and grinding on flat or contoured workpieces.

Key Features

• Type 29 depressed center profile for aggressive grinding angle and increased contact area
• 60 grit aluminum oxide abrasive at medium grade for fast stock removal
• 8600 RPM maximum speed rating for use with standard 7 inch angle grinders
• 7/8 inch arbor hole fits common arbor connector type on angle grinders
• Compatible with steel, stainless steel, aluminum, and non-ferrous materials

Compatibility

Designed for use with angle grinders accepting a 7 inch, 7/8 inch arbor hole grinding wheel. Suitable for material applications including steel, stainless steel, aluminum, and non-ferrous metals.

Installation Notes

Installation should be performed by qualified personnel following ANSI B7.1 safety standards for abrasive wheel mounting. Always power down and disconnect the angle grinder before mounting or removing the wheel. Verify that the tool's rated RPM meets or exceeds the wheel's 8600 RPM maximum before use, and inspect the wheel for cracks or damage prior to each installation. Proper guard placement must be confirmed before operating the grinder.
