Walraven 2061016 W6000 Insulated Clamp 1/2 inches

Product Description

The WALRAVEN 2061016 W6000 Insulated Clamp is designed for pipes requiring insulation for thermal isolation of steel, copper, stainless steel, or plastic pipes. It is designed for use in combination with soft insulation material. The clamp features vapor-proof gluing to pipe insulation and offers excellent thermal and mechanical properties.

• For installation of thermal isolated steel, copper, stainless steel or plastic pipe
• One-piece design - no loose parts
• Easier, faster, safer - installs with one hand

Product Highlights

Insulated clamp with a one-piece design, suitable for various pipe materials, ensuring easy and safe installation with excellent thermal and mechanical properties.

Product Information

Standard Information

• Brand: WALRAVEN
• Manufacturer Part Number: 2061016

Technical Specifications

• material: Clamp: made of steel 1.0242; Insulation shell: PIR thermally hardening foam (core), synthetic rubber (sides) and vapor-proof layer of black PVC
• surface treatment: High grade Zn-Mg based coating (600 hours salt spray)
• D (mm): 14 - 16
• D / CTS ("): 1/2
• D / ACR ("): 5/8
• F a,z (lbf): 68
• Total Height H (mm): 69
• Total Width W (mm): 42
• Total Depth DtT (mm): 70
