Wal-Rich 2817046 Dresser Handiband Repair Clamp 8 inches x 12 inches

Product Description

The WAL-RICH 2817046 Dresser Style 118 Handiband Clamp is a field-proven, low-cost band-type repair clamp designed for quick and permanent repair of small leaks and holes in steel piping. Constructed from stainless steel for corrosion resistance, with ductile iron lugs and alloy bolts and nuts, this 8" x 12" clamp features a Dresser rubber compound gasket that resists oils, hydrocarbons, gasoline, and condensates. It can withstand up to 150 PSI and 150 degrees F.

• Quick repair of small leaks and holes in steel piping
• Fast, easy, and foolproof installation
• Made of stainless steel for corrosion resistance

Product Highlights

Durable stainless steel repair clamp with a resistant gasket for steel piping leaks.

Product Information

Standard Information

• Brand: WAL-RICH
• Manufacturer Part Number: 2817046

Technical Specifications

• Size: 8" x 12"
• Material: Ductile Iron, Alloy Steel, Stainless Steel
• Dresser Part Number: 0118-0330-009
• Overall Length: 12 inches
• Gasketing: Plain Grade 27 Gridded Gasketing
• Band Material: T-304 Stainless Steel Band
• Lugs Material: E-Coated Ductile Iron Lugs
• Max Pressure: 150 PSI
• Max Temperature: 150 Degrees F
• Bolts & Nuts Material: Alloy to ANSI A21.11
