Wal-rich 0090-0005-082 Dresser Style 2 Coupling with Armored Gaskets Cast Iron E-coated 5 Inches

Product Description

The WAL-RICH 0090-0005-082 is a Dresser Style 2 Coupling built for demanding pipe connection applications in water, gas, and industrial systems. This coupling features Armored Grade 27 gaskets that provide a reliable, leak-resistant seal even in high-pressure and high-temperature environments. It is constructed from cast iron and finished with an E-Coat treatment, which gives the exterior strong corrosion resistance and long service life in the field. The overall length is 5 inches, and it weighs 6.2 pounds, making it a solid, heavy-duty fitting suited for permanent installations. It is rated for up to 150 PSI maximum working pressure and handles fluid temperatures up to 212 degrees F, which covers a wide range of water and process piping conditions. Dresser-style couplings like this one are used by plumbers, pipefitters, and utility contractors to join plain-end pipe sections without threading or welding. They allow for minor misalignment and pipe movement, which is especially useful in repair situations or where pipes need to be connected quickly in tight conditions. The E-Coat finish is applied by electrodeposition, giving the casting consistent coverage on all surfaces, including internal recesses. This protects the iron body from oxidation and extends the product life in wet or underground environments. Grade 27 armored gaskets are designed for tougher service conditions, incorporating a reinforcing element that prevents gasket blowout under pressure spikes. This product is compatible with standard Dresser Style 2 replacement components and follows the same dimensional footprint used by original Dresser couplings. HVAC technicians, plumbers, and mechanical contractors keep Dresser-style couplings in their supply inventory for waterline repairs and new piping runs on cast iron, steel, and ductile iron pipe systems.

• Dresser Style 2 coupling design fits plain-end pipe for fast, reliable connections without threading or welding
• Armored Grade 27 gaskets provide reinforced sealing performance and resistance to pressure surges up to 150 PSI
• Cast iron body with E-Coat finish delivers superior corrosion protection for long-term service in wet and underground applications

Product Highlights

The WAL-RICH 0090-0005-082 Dresser Style 2 Coupling combines a cast iron body, E-Coat corrosion protection, and Armored Grade 27 gaskets to deliver a heavy-duty pipe coupling rated for 150 PSI and 212 degrees F. It is a direct-fit solution for plumbers and pipefitters working on plain-end pipe repair and installation.

Product Information

Standard Information

• Brand: WAL-RICH
• Manufacturer Part Number: 0090-0005-082

Technical Specifications

• Weight: 6.2 pounds
• Overall Length: 5 inches
• Gasket Type: Armored Grade 27
• Body Material: Cast Iron
• Finish: E-Coated
• Maximum Pressure: 150 PSI
• Maximum Temperature: 212 degrees F
