Wal-rich 0038-0005-011 Dresser Style 38 Coupling with Plain Gaskets 1-1/4 Inch

Product Description

The WAL-RICH 0038-0005-011 is a Dresser Style 38 coupling designed for 1-1/4 inch pipe connections in demanding water and gas distribution systems. This coupling is built for use by plumbers, utility contractors, and pipeline maintenance crews who need a reliable, pressure-rated mechanical joint for connecting plain-end pipe sections without threading or welding. The Style 38 design is one of the most widely used coupling formats in the industry, valued for its straightforward installation and consistent sealing performance across a range of pipe materials including steel, cast iron, and ductile iron pipe.

The 0038-0005-011 features a carbon steel body finished with a fusion-bonded epoxy coating. This coating provides strong resistance to corrosion both inside and outside the coupling, making it suitable for underground installations and environments where moisture exposure is a concern. The fusion-bonded epoxy finish also meets many municipal and utility specifications for potable water applications, which is a key consideration for waterworks and distribution projects.

Plain Grade 27 gaskets are included with this coupling. These gaskets create a tight, leak-resistant seal around the pipe and are compatible with a variety of pipe outside diameters within the 1-1/4 inch nominal size range. The overall length of this coupling is 5 inches, providing sufficient engagement on both pipe ends for a secure mechanical connection. The unit is rated for a maximum working pressure of 1500 PSI as noted on the manufacturer spec sheet, and it can handle fluid temperatures up to 212 degrees F. The assembled weight is 4 pounds. This coupling is a standard replacement or new-installation part for waterworks, plumbing, and industrial piping projects.

• Carbon steel body with fusion-bonded epoxy coating for corrosion resistance in underground and wet environments
• Includes Plain Grade 27 gaskets for a reliable, leak-resistant pipe seal
• Rated up to 1500 PSI maximum working pressure and 212 degrees F maximum temperature

Product Highlights

The WAL-RICH 0038-0005-011 Dresser Style 38 Coupling delivers a proven mechanical pipe connection solution for 1-1/4 inch pipe, combining a durable epoxy-coated carbon steel body with high-pressure and high-temperature ratings suited for waterworks and industrial piping applications.

Product Information

Standard Information

• Brand: WAL-RICH
• Manufacturer Part Number: 0038-0005-011

Technical Specifications

• Pipe Size: 1-1/4 inches
• Overall Length: 5 inches
• Body Material: Carbon Steel
• Coating: Fusion-bonded Epoxy
• Gasket Type: Plain Grade 27
• Maximum Pressure: 1500 PSI
• Maximum Temperature: 212 Degrees F
• Weight: 4 pounds
