Product Description
The WAGO 811-314 Terminal Block is designed for reliable and efficient power distribution within a 24Vdc system. This compact and durable unit is ideal for a wide range of applications, including industrial control systems and automation networks.
- Features a single-deck design with a fused disconnect mechanism.
- Includes a blown-fuse indicator for easy maintenance and monitoring.
- Supports wire sizes from #16AWG to #6AWG, ensuring versatile use.
Product Highlights
Constructed from high-quality polyamide (PA66) and equipped with CAGE-CLAMP spring connections, the WAGO 811-314 terminal block offers exceptional durability and easy installation on a DIN-35 rail. With dimensions tailored for space-saving installation, this terminal block is an excellent choice for streamline wiring setups.
Product Information
Standard Information
-
Brand: WAGO
-
Dimensions: Height 105 mm x Width 17.5 mm x Depth 55 mm
Technical Specifications
-
Current Rating: 32 A
-
Voltage Rating: 24V
-
Operating Temperature: -35 to +85°C
-
Connection Type: Terminals (Cage-clamp)
-
Color: Light Gray
-
Material: Polyamide (PA66)
-
Mounting Type: DIN Rail
