WAGO 788-102 Relay Base Socket Module 250VAC/250VDC 8A

Product Description

The WAGO 788-102 Relay Base Socket Module is engineered for superior performance in industrial settings. Ideal for 2C/O relays, this module supports a control voltage of 250VAC/250VDC and sustains a rated current up to 8A continuously.

• Equipped with push-in CAGE CLAMP spring connections for robust and reliable connectivity.
• Features a slim 15mm width and DIN-35 rail mounting for easy installation.
• Designed with IP20 protection to ensure durability and safety in diverse environments.

Product Highlights

Its reinforced insulation guarantees safe operation. The integration of advanced contact technology facilitates enhanced response times and a more stable performance. This socket module is a crucial component for streamlined motor control and automation systems.

Product Information

Standard Information

• Mounting Type: DIN Rail
• Insulation Class: Reinforced

Technical Specifications

• Catalog Number: 788-102
• Brand: WAGO
• Connection Type: Terminals (Cage-clamp)
• Conductor Range: 14-22 AWG
• Dimensions: H86mm x W15mm x D54mm
• Weight: 30.72 grams
• RoHS Compliant: Yes
• Country of Origin: China
