WAGO 773-162 WAGO ZZZZZ TERMINAL BLOCK PLUGGABLE, 2 POSITION, 16-12AWG 28K2290

Product Description

The WAGO 773-162 is a pluggable terminal block designed for efficient electrical connections. It accommodates wire sizes ranging from 16 to 12 AWG and is rated for a voltage of 400V and a current of 24A.

• Connects solid and stranded wires
• Compact design suitable for junction boxes
• UL and CSA approved for safety and reliability

Product Highlights

This wire connector enhances connection speed and reliability while ensuring compliance with industry standards.

Product Information

Standard Information

• Manufacturer: WAGO Corporation
• UPC: 04491813632

Technical Specifications

• Application: For Junction Boxes
• Color: Yellow/Clear
• Dimensions: 0.516 in H x 0.362 in W x 0.768 in D
• Manufacturer Part Number: 773-162
• Series: 773
• Specifications: 24 A, 2 Conductor, 2 Pole, 0.47 in Stripe
• Standards/Approvals: LR46759 CSA Certified | RoHS Compliant | UL E69654 Listed
• Temperature Rating: 105 deg C
• Type: Push-In Wire
• Voltage Rating: 400 VAC
