WAGO 721-112/037-000 1-Conductor Female Connector Cage Clamp 2.5 mm Pin Spacing 12-Pole

Product Description

The WAGO 721-112/037-000 is a 1-conductor female connector that features a cage clamp design. It has a pin spacing of 2.5 mm and is suitable for 12-pole applications. This connector is designed to prevent mismating, ensuring a reliable connection. The lateral locking levers provide additional security and stability.

• Compatible with 12-28 AWG conductor range
• Rated for a maximum current of 16 A
• Constructed from durable polyamide (PA66)

Product Highlights

This connector is ideal for use in industrial and commercial wiring applications. Its cage clamp connection type allows for quick and secure wire insertion without the need for tools.

Product Information

Standard Information

• Catalog Number: 721-112/037-000
• Manufacturer: WAGO

Technical Specifications

• Country of Origin: Germany
• Conductor Range: 12-28 AWG
• Current Rating: 16 A
• Voltage Rating: 320 V
• Material: Polyamide (PA66)
• RoHS Compliance: Yes
• Weight: 22.704 grams
• Width: 3.016 inches
• Height: 0.563 inches
• Depth: 1.165 inches
