WAGO 231-110/031-000 1-Conductor Female Connector Cage Clamp 2.5 mm Pin Spacing 5 mm 10-Pole Clamping Collar

Product Description

The WAGO 231-110/031-000 is a 1-conductor female connector designed for use in various electrical applications. It features a cage clamp design for secure connections. This connector has a pin spacing of 2.5 millimeters and supports a conductor range of 12 to 28 AWG. Ideal for use in wiring projects and electrical installations, the connector is reliable and efficient.

• Conductor range: 12 to 28 AWG
• Current rating: 16 A
• Material: Polyamide (PA66)

Product Highlights

This connector is fabricated using high-quality materials, ensuring durability and performance in demanding environments.

Product Information

Standard Information

• Brand: WAGO
• Country of Origin: Germany

Technical Specifications

• Catalog Number: 231-110/031-000
• Actuator: Operating tool
• Voltage Rating: 320 V
• Connection: Cage clamp
• RoHS Indicator: Yes
• Mounting: Flange
• Width: 2.551 inches
• Height: 0.563 inches
• Depth: 1.041 inches
