WAGO 231-109/026-000 1-Conductor Female Connector Cage Clamp 2.5 mm Pin Spacing 5 mm 9-Pole

Product Description

The WAGO 1-Conductor Female Connector with MPN 231-109/026-000 is designed for reliable electrical connections in various applications. This connector features a cage clamp design, suitable for use with conductors ranging from 12 AWG to 28 AWG. The gray connector is compliant with RoHS standards and has a current rating of sixteen amps.

• Compatible with conductor sizes from 12 AWG to 28 AWG
• Features a cage clamp connection for secure performance
• Rated for a maximum voltage of three hundred twenty volts

Product Highlights

This connector is ideal for connecting electrical conductors securely and efficiently. It is commonly used in industrial applications where durability and reliability are critical.

Product Information

Standard Information

• Catalog Number: 231-109/026-000
• Manufacturer: WAGO

Technical Specifications

• Item Type: 1-Conductor Female Plug
• Material: Polyamide (PA66)
• Current Rating: 16 A
• Voltage Rating: 320 V
• Conductor Range: 12-28 AWG
• Depth: 1.041 inches
• Width: 1.831 inches
• Height: 0.563 inches
• Weight: 16.27 grams
• Country of Origin: Germany
• RoHS Indicator: Yes
