WAGO 231-105/026-000 1-conductor female connector CAGE CLAMP 2.5 mm Pin spacing 5 mm 5-pole 2,50 mm

Product Description

The WAGO 1-conductor female connector with MPN 231-105/026-000 is designed for reliable electrical connections. This connector features a cage clamp mechanism for secure attachment. It is suitable for applications requiring a pin spacing of five millimeters and a conductor range of twelve to twenty-eight AWG. The connector's robust design and materials ensure durability and compliance with industry standards.

• Made for conductor sizes from 12-28 AWG
• Rated for 16 Amperes
• Country of origin: Germany

Product Highlights

Excellent for use in various electrical projects, the WAGO female connector ensures a strong, low-resistance connection.

Product Information

Standard Information

• Catalog Number: 231-105/026-000
• Brand: WAGO

Technical Specifications

• Current Rating: 16 A
• Voltage Rating: 320 V
• Material: Polyamide (PA66)
• Color: Gray
• Conductor Range: 12-28 AWG
• Width: 1.043 inches
• Height: 14.3 mm / 0.563 inches
• Depth: 26.45 mm / 1.041 inches
• Weight: 9.299 grams
