Wac WL-LED110-C-WT Landscape 120 Step and Wall Lighting 3.50 watt

Product Description

The WAC WL-LED110-C-WT is an LED horizontal scoop step and wall light designed for seamless integration into various architectures. It features an interchangeable magnetic faceplate with no visible hardware, providing enhanced energy-efficient functionality. This luminaire offers optimized light output to adequately illuminate stairs, walls, and walkways with minimal glare. The light engine is IP66 sealed, making it suitable for both indoor and outdoor applications, and it operates on 120V or 277V systems.

• Wet location rated to IP66 standards for indoor and outdoor installations.
• Smooth and continuous ELV dimming to 10% with an Electronic Low Voltage dimmer.
• Die-cast aluminum construction with magnetic faceplate installation and tamper-proof non-visible hardware.

Product Highlights

Energy-efficient LED step and wall light with 90 CRI and 3000K color temperature, offering 50,000 hours rated life.

Product Information

Standard Information

• Brand: WAC
• Manufacturer Part Number: WL-LED110-C-WT
• Country of Origin: China

Technical Specifications

• Brand: WAC Lighting
• Category: Step and Wall Lighting
• Product Type: LED Horizontal Scoop Step and Wall Light
• SKU: WL-LED110-C-WT
• UPC: 790576458366
• CRI: 90
• Color Temperature: 3000K
• Dimmable: Yes
• Lamp Type: Integrated LED
• Replacement Bulb MPN: 4EPD500511
• Bulbs Included: Yes
• Lead Wire Length: 6.00 inches
• Lumens: 5
• Number of Bulbs: 1
• Socket Type: LED Module
• Total Wattage: 3.5 W
• Input Voltage: 120 VAC
• Max Wattage: 3.50 W
• Backplate Extension: 1.75 inches
• Backplate Height: 5 inches
• Backplate Width: 3.13 inches
• Extension: 1.75 inches
• Height: 3.13 inches
• Length: 5 inches
• Width: 1.75 inches
• ADA Compliant: Yes
• Country of Origin: Thailand
• Installation Position: Light-One Side Each
• Title 24 Compliant: Yes
• Certifications: ETL, cETL, IP66 Wet
• Mounting Type: Ceiling/Wall
• Location Rating: Interior/Exterior
• J-Box Compatibility: Fits into 2x4 J-Box with minimum inside dimensions of 3"L x 2"W x 2"D
• Wiring: Direct wiring for 120V or 277V, no driver necessary
• Power Connection: Hardwired
• Dimming Type: Low Voltage Electronic (ELV)
• Bulb Shape: LED Module
• Delivered Lumens: 4
• Beam Angle: 60 degrees
• Rated Life: 50000 hours
• Construction Material: Die-cast aluminum
• Complete System: Yes
• Lens Type: Frosted Glass
• Bulb Details: 1 x LED/3.5W/120V Integrated LED module
• Step Light Type: Single Gang Switch Box Mount, Deck / Brick Step Lights, Line Voltage
• Design Style: Functional
• Lens Material: Glass
• Sensor Type: Light
• Watts Per Bulb: 3.5 W
• Style: Contemporary
