Wac r6drak-a9cs-bk lotos r retrofit adjustable downlight 13w 6 inch 5cct 50 degree

Product Description

The WAC R6DRAK-A9CS-BK Lotos R Retrofit Adjustable Downlight delivers 1270 lumens with a 5CCT switchable function from 2700K to 5000K and a 90 CRI. Operating at 13W with 120-277V input, this IC Rated and Airtight fixture supports ELV and TRIAC dimming from 100-5%. It features a multiple LED array for uniform illumination and a rotatable multi-axis gimbal ring, designed for easy installation into standard 6-inch recessed cans.

• Delivered Lumens: 1270lm
• CCT: 2700K/3000K/3500K/4000K/5000K
• IC Rated, Airtight

Product Highlights

5-CCT Switchable between 2700K and 5000K, multiple LED array for uniform illumination, and rotatable multi-axis gimbal ring.

Product Information

Standard Information

• Brand: WAC
• Manufacturer Part Number: R6DRAK-A9CS-BK
• Country of Origin: China

Technical Specifications

• Beam Angle: 50°
• Color Temperature: 2700K/3000K/3500K/4000K/5000K
• CRI: 90
• Lumens: 1270
• CBCP: 1891
• Wattage: 13W
• Input Voltage: 120-277V
• Frequency: 50/60Hz
• Dimming Type: ELV, TRIAC
• Dimming Range: 100-5%
• Rated Life: 50,000 Hours
• Material: Steel
• Lens Type: Frosted TIR lens
• Recessed Size: 6"
• Driver Location: Concealed within fixture
• Lamp Type: LED Module
• Efficacy: 98 Lm/W
• Beam Spread: Flood
• Number of Lamps: 1
• Lamp Included: Yes
• Socket Type: LED Module
• Certifications: IC Rated, Airtight, ETL/cETL, CSA CAN Wet, Title 20, Title 24, CEC Compliant, Energy Star 2.0 Certified, JA8-2016, Wet Location Rated
• Wiring Type: Hardwired
• Location Rating: Interior/Exterior
• Mounting Type: Retrofit over 6" recessed can
• Downlight Type: Regressed, Standard Residential
• CCT Selectable: Yes
